Pipe Threads

G 1/8, 1/4   Parallel (F)

- Standard

BSPTr./NPT

- Optional

Body Material

Zinc Alloy   die-cast

Filter Element   Size

5, 25, 40   micron.

Filter Element   Material

Plastic   (Polypropylene)

- Standard

Sintered Bronze

- Optional

Bowl Material

Transparent   Polycarbonate

- Standard

Metal Zinc   diecast

- Optional

Maximum Inlet   Pressure

with P.C. Bowl   Manual and Automatic Drain

150 psig (10.5   bar)

with Metal Bowl   Manual Drain

250 psig (17.5   bar)

with Metal Bowl   Automatic Drain

150 psig (10.5   bar)

Max. Operating   Temp. (ambient)

with PC Bowl:   50℃ (125℉)

with Metal Bowl:   80℃ (175℉)

Drain

Manual -   Standard

Automatic -   Optional (operates only on flow change)

Regulator Type

Relieving -   Standard

Non-Relieving  - Optional

Pressure   Adjustment

Non-rising   plastic knob

Regulated   secondary outlet pressure (Spring Range) and recommended pressure gauge   ranges available (in kg/cm²)

Spring Range

Gauge Range

1-10 psi (0.07   to 0.70 bar)

0-35 psi (0 to   2.5 bar)

3-30 psi (0.21   to 2.10 bar)

0-35 psi (0 - 25   bar)

5-50 psi (0.35   to 3.50 bar)

0-60 psi (0 to   4.0 bar)

10-100 psi (0.70   to 7.0 bar)

0-150 psi (0 to   10.0 bar)

15-150 psi (1.00   to 10.0 bar)

0-220 psi (0 to   16.0 bar)

Std. Nominal   flow at 10 bar (150 PSI) Inlet pressure 6 bar (87 PSI ) set pessure and a   drop of 1 bar (14.5 PSI) from set

G 1/8"

18 scfm (8.4   dm3/sec) CV (0.33)

G 1/4"

19 scfm (9.0   dm3/sec) CV (0.35)

Gauge size

40 mm (Dial   Size)

Gauge Port size

Rc 1/8 BSPTr.

Gauge connection

Back

Mounting Bracket

Optional

Panel mounting

Standard -   Available

Pressure Gauge   (scale)

Kg/cm² (PSI)

- Standard (For   Domestic Market)

Bar (PSI)

- Standard   (Export)
